Description
  • A Discharge Hook is a special discharging device used to deenergize capacitors and other voltage retaining components before maintenance work is performed.
  • The first stick typically used is called a discharge stick.
  • The discharge stick removes the stored energy through a resistor connected to ground.
  • Non Linear Carbon Discharge Resistor Type Discharge Rods are used to discharge dead system having limited fault levels and also to discharge the static & induced charges in the dead system or equipment, particularly in transmission lines, cables, transformers, reactors, large bus bar systems, switch-gears etc.
  • A Discharge Hook is used to drain capacitive voltage.
  • The probe is first used to make contact, then the hook can be used to make direct contact bypassing the fuse.
  • The fuse gives added protection in case initial contact is accidentally made on energized equipment. Fuse is rated at 8 kV maximum, 6 amperes continuous.
  • File Type: MA,MB,FBX.
  • Number of Polygons: 3121.
  • Number of Vertices: 3172
  • Number of Tris: 6316.
  • Texture format PNG.
  • Texture resolution 2K.
