Professional CAD Model of a Hydraulic Bale Fork 3D model
thumbnail
thumbnail
thumbnail
thumbnail
thumbnail
thumbnail
thumbnail
DESCRIPTION

A well-designed hydraulic bale fork is an essential tool for efficiently transporting and handling hay or straw bales. A self-made hydraulic bale fork should be built with sturdy steel construction to ensure durability and high load capacity. The frame should feature reinforced welding and a robust hydraulic system for smooth and reliable operation.

Key features of a high-quality DIY hydraulic bale fork:

  • Heavy-duty steel frame for long-lasting performance
  • Hydraulic cylinders for precise bale gripping and release
  • Adjustable tines to handle different bale sizes
  • Secure locking mechanism to prevent slippage
  • Quick-attach system for easy mounting on tractors or loaders

For maximum efficiency, high-quality hydraulic components should be used, ensuring smooth operation and minimal maintenance. The design should focus on practicality and safety, making it an indispensable tool for agricultural work.

  • The bill of materials is included as a PDF
