3D Model Engine Cylinder Block with Piston Assembly 3D model
thumbnail
DESCRIPTION

A detailed CAD model of an air-cooled engine cylinder block complete with piston and connecting rod, designed for mechanical visualization, simulation, or educational purposes.

Key Features:

Finned Cylinder Block: Designed for heat dissipation, suitable for small single-cylinder engines or air-cooled applications.

Precision Piston: Includes ring grooves and pin slot details for realistic assembly.

Connecting Rod Assembly: Attached to the piston via a realistic joint, ready for motion or simulation analysis.

Applications:

Mechanical engineering education

Thermodynamic or motion simulation (FEA/CFD)

Engine concept development or prototyping

Design by Veldi Handi Rahmadan

Related Tagsmachineryengineeringenginepistoncylinderblockcombustionautomotivemechanicalcad3dmodelfusion360
aircooled
industrialmachineindustrial machine
