AT dishwasher 3D model

3D model of the AT dishwasher. The AT dishwasher is a low-cost dishwasher without doors or hinges. Instead, a plastic panel can be removed from the front using clamps. Once this is done, the baskets can be hung slided inside it. A special piping system allows to reuse greywater (slightly dirty (allready used) water with soap)) several times to wash the dishes/crockery. Used water with soap is collected from the bottom of the bishwasher and recirculated. After reusing the water a number of times it is refed with new (clean) water. All of this is done using valves, controlled automatically by a printed circuit board (PCB). The green part on the piping represents the pump. Natural cleaning agent is done in the soap box for mixing with the water. At the bottom on the 3 plastic panels is a heater coil that allows air to be heated (for the drying, after the washing). A valve is present on the top plastic panel for releasing the moist air to the atmosphere. Both are controlled by the PCB. See the 'Purchasing_the_models' link at appropedia's AT_CAD_Team for additional information on the model
