Cabinet hinge 3D model

There are Cabinet hinge SOLIDWORKS parts and assembly files in rar. In addition, there are 3 different bolts available for mounting the cabinet hinge to the furniture. The product assembly dimensions are shown in the picture.

Model dimensions are 1:1 (99.0%) scale taken from a real product.

File formats available on request:

• SOLIDWORKS (sldprt, sldasm)
• SOLIDWORKS Composer (smg)
• Polygon (ply)
• IGES (igs)
• STL
