DESCRIPTION

The Oasis is a 25Gps backplane connector, and the 3pair is currently under development.The spacing between wafers is 2mm and the vertical spacing is 1.4mmThe force to mate a receptacle connector and compatible header shall not exceed 0.6 Newtons per contact. The unmating force shall not be less than 0.15 Newtons per contact. After the durability tested, the unmating force shall not be less than 0.12 Newtons per contact.The following details apply:a. Cross Head Speed – 25.4 mm or inch per minute.b. Utilize free floating fixtures.c. Reference EIA-364-13.
