Hitano ECR capacitors

Hitano ECR capacitors 3D model

Description

Hitano ECR capacitors of all sizes. Datasheet - http://www.hitano.com.tw/wp-content/uploads/doc/ECR_20160615.pdf

Models were designed to use it in PCB CADs (Altium Designer, DipTrace, etc.).

They were made using configurations in SolidWorks, so one file includes all possible configurations of capacitors. As you see, there is two models for different ways of installation on your PCB. The first one is vertical installation, the second one is horizontal installation. Pictures fully describes it.

ZIP archive includes all possible configurations in STEP AP214 format.

Model's names meaning: D - capacitor's diameter; H - capacitor's height; A - leads spacing.

Item rating
0 0
Hitano ECR capacitors
$3.00

Royalty Free License
Hitano ECR capacitors
$3.00

Royalty Free License
Response - % in - h
3D Modeling
Hire me

3D Model formats

Format limitations
Native
  • SolidWorks (.sldprt, .sldasm, .slddrw) (2 files)5.86 MB
Exchange
  • STEP AP214 (.stp)1.03 MB

3D Model details

  • Publish date2020-04-16
  • Model ID#2371972
  • Animated
  • Rigged
  • VR / AR / Low-poly
  • PBR
  • Geometry -
  • Polygons 0
  • Vertices 0
  • Textures
  • Materials
  • UV Mapping
  • Unwrapped UVs Unknown
  • Plugins used
  • Ready for 3D Printing
