Complete Architectural CAD System Real Project ProWorkflow 3D model
thumbnail
thumbnail
thumbnail
DESCRIPTION

Professional architectural and structural CAD drawing set from a real commercial project.

This package includes a complete workflow system used in a professional architecture office, featuring:

ARCHITECTURAL:

  • Floor plans (N-FLR-PL)
  • Sheet layouts (A01–A06)
  • Title blocks and presentation sheets

STRUCTURAL:

  • Glulam beam details (GLULAM-S)
  • Truss sections (TRUSSSEC)
  • I-joists (TJI-14, TJI-16)
  • Wood framing details (TG series)

CONSTRUCTION:

  • CSI-based construction details (02520 series)
  • Pavement and site sections

SYSTEM FILES:

  • AutoLISP automation scripts
  • CAD standards and layer systems
  • Blocks and reusable components

FORMAT:

  • DWG (AutoCAD compatible)

This is a legacy professional CAD system (late 1990s), ideal for:

  • Architectural reference
  • Learning CAD workflows
  • Construction detailing study

Note:Preview images are representative of the included CAD content.

Related Tagscadautocaddwgfloorplanstructuralconstructionblueprintbuildingrestauranttechnicaldrawingengineeringwoodtruss
