SolidWorks cfm56-7b Complete model

SolidWorks cfm56-7b Complete model 3D model


The CFM56-7B is the exclusive engine for the Next-Generation single-aisle airliner

I offer this model in the SolidWorks and Parasolid .format for those who may wish to actually build this fine Launch Engine. Can be used for processing and production.However, I cannot warrant the usability of the CAD model for actual construction. This is a modifiable parameterized format file, which is also the native software format.I believe you can do a lot of things using the 3D model of this format. In SolidWorks format, there are parameterized x_t files.You can import software such as CATIA to modify.

The format for sale includes: SolidWorks 2016 Parasolid (x_t) Cinema 4D R19 (Vray 3.4 rendering) 3D Max 21018 (Material-free mapping) OBJ

High detailed and accurated CFM56-7B Turbofan Engine 3d modelUsing cinema 4d vray rendering. This is a complete 3D model, the internal parts are also very complete.The 3 d model is very accurate and detailed. All the parts according to the real photos, and these parts can be move, rotate, deformation.This is an assembly, parts can be disassembled. Modeling reference to hundreds of photos on the network, and a lot of relevant documentation. All animatable parts are (fan,high pressure turbine,low pressure turbine, hp compressor, ip compressor, shaft, turbines, rotors, plugs, cowls etc).

This high resolution 3D model allows for extreme rendering. 3d model Originally built in SolidWorks to achieve highest accuracy.

rillater 2023-10-17 09:17:59 UTC
This 3D object is a masterpiece! The designer has done an excellent job.
Item rating
0 0
SolidWorks cfm56-7b Complete model
Royalty Free License
SolidWorks cfm56-7b Complete model
Royalty Free License
Response 71% in 48.0h
3D Modeling
3D Print Modeling
Hire me

3D Model formats

Format limitations
  • SolidWorks 2016 (.sldprt, .sldasm, .slddrw)300 MBVersion: 2016Renderer: Mental Ray 2016
  • Autodesk 3ds Max 2018 (.max)429 MBVersion: 2018Renderer: Default (Scanline)
  • Cinema 4D R19 (.c4d)312 MBVersion: R19Renderer: V-Ray 3.7
  • OBJ (.obj, .mtl)219 MB

3D Model details

  • Publish date2018-09-08
  • Model ID#991492
  • Animated
  • Rigged
  • VR / AR / Low-poly
  • PBR
  • Geometry Nurbs
  • Polygons 13,932,727
  • Vertices 6,997,892
  • Textures
  • Materials
  • UV Mapping
  • Unwrapped UVs Unknown
  • Plugins used
  • Ready for 3D Printing
