DESCRIPTION

Metal flange DIN2566 (PN16) 3/4 Inch BSP for Autodesk Inventor

Free 3D CAD model:

  • Description: Threaded flange
  • Diameter: 3/4"
  • Material: Metal (stainless steel)
  • Connections: BSP female x flange PN16
  • File format: Autodesk Inventor .ipt

    You can use this CAD model directly in:■ Autodesk Inventor 2015■ Autodesk Inventor 2016■ Autodesk Inventor 2017

    This is a sample CAD model from the full range library BSP threaded metal fittings and valves. This Content Center library for Autodesk Inventor contains many hundreds premium quality 3D piping parts for mechanical engineers.Click here for all details about this library.

    I hope you can use this CAD model in one of your engineering projects. Feel free to share, like or comment...

    Freerk de With, Wyalo 3D CAD models
