Discharge Rod Low-poly 3D model
Verification details of the FBX file
Files
Binary FBX
Scene
No unsupported objects
Geometry
No N-gonsNo faceted geometryManifold geometry
Textures and Materials
PBR texturesNo embed texturesSquare texturesPower of 2 texture sizesAssigned materials
UVs
No UV overlapsUV unwrapped model
Naming
Allowed characters
Description
- Non Linear Carbon Discharge Resistor Type Discharge Rods are used to discharge dead system having limited fault levels and also to discharge the static & induced charges in the dead system or equipment, particularly in transmission lines, cables, transformers, reactors, large bus bar systems, switch-gears etc.
- The WDL Capacitor Discharge Rods are used for the removal of electrostatic charge from disconnected circuits, before undertaking maintenance work.
- Manufactured from 1.2-metre-long lightweight insulating tubing and fitted with a dischargeable hook.
- The discharge stick is a touch device, designed for just that, discharging electrical conductors that where once energized.
- Connect the earthing clamp to ground and touch the now un-energized conductor to discharge.
- The discharge stick is to be used by trained personnel.
- Safe discharge rods allow technicians to conduct the safe damp discharge of the residual charge on an electrical cable or piece of equipment by limiting the discharge current.
- The instruments are used by extensively by electric utility workers when engaged on live-line working on high voltage electric power lines.
- File Type: MA,MB,FBX.
- Number of Polygons: 3760.
- Number of Vertices: 3879.
- Number of Tris :7556.
- Texture format PNG.
- Texture resolution 2K.
Discharge Rod
Royalty Free License
Discharge Rod
Royalty Free License
3D Modeling
Low-poly Modeling
Lighting
Rendering
Rigging
Skinning
UV mapping
Texturing
Shaders
Particles
Post Production
Animating
PBR modeling
Grooming
3D Model formats
Format limitations
- Autodesk Maya (.ma, .mb) (2 files)1.38 MBVersion: 2023Renderer: Arnold 2023Version: 2023Renderer: Arnold 2023
- Autodesk FBX (.fbx) (2 files)1.38 MB
- OBJ 2023 (.obj, .mtl)814 KB
3D Model details
- Ready for 3D Printing
- Animated
- Rigged
- VR / AR / Low-poly approved
- PBR approved
- Geometry Polygon mesh
- Polygons 3,760
- Vertices 3,881
- Textures
- Materials
- UV Mapping
- Unwrapped UVs Non-overlapping
- Plugins used
- Publish date2024-07-02
- Model ID#5379365
