DIN-EN Butterfly Valves - Lug Type - Red 3D model
thumbnail
thumbnail
DESCRIPTION

IN THIS 3D CAD COLLECTION:

  • 40 Different 3D CAD files.
  • F3D and STEP file types.
  • Lug type butterfly valves with connections for DIN-EN flanges (European Standard)
  • Diameters DN50 up to DN300
  • Pressure Rating PN16
  • Manual and pneumatic operation
  • Open- and closed situation
  • Valve body color Red

THE FILE TYPES:

  • .step (STP): This file type is often used for exchanging 3D models and is compatible with most CAD software, such as SolidWorks, Inventor, AutoCAD, and Fusion 360.
  • .f3d (Fusion 360): Suitable specifically for Autodesk Fusion 360 users, it allows you to import the models directly into this popular design application.
