8 Inch Fluidyne Aspiration Assembly 3D model

The jet aspirating nozzle assembly is mounted directly to the jet pump. Liquid from below the surface is pumped through nozzles. In passing through the nozzle, the liquid flow increases in velocity. Air is drawn into the low pressure zone in the aspirator and mixes with the liquid in an outer nozzle, forcing oxygen to transfer into solution
