90L B34a Left IEC electric motor - 3D CAD model

90L B34a Left IEC electric motor - 3D CAD model 3D model

Description

Electric motor IEC 90L B34a - IM2101 (face-foot mount)

■ 2,2 kW - 3000 r.p.m. (2 pole) ( 3,0 Horse Power )
■ 1,5 kW - 1500 r.p.m. (4 pole) ( 2,0 Horse Power )
■ 1,1 kW - 1000 r.p.m. (6 pole) (1,5 Horse Power )
■ 0,55 kW - 750 r.p.m. (8 pole) (0,75 Horse Power)
Terminal box position = left


Is this not the type of motor you need?

Click here for our 3 step motor-selection tool and download the right CAD model in less than a minute...
Item rating
0 0
90L B34a Left IEC electric motor - 3D CAD model
$3.00

Royalty Free License
90L B34a Left IEC electric motor - 3D CAD model
$3.00

Royalty Free License
Response - % in - h

3D Model formats

Format limitations
  • STEP (.stp)2.53 MB
  • AutoCAD 2010 (.dwg)915 KB
  • Autodesk Inventor 2015 (.iam, .ipt)2.62 MB

3D Model details

  • Publish date2016-07-12
  • Model ID#626463
  • Animated
  • Rigged
  • VR / AR / Low-poly
  • PBR
  • Geometry Other
  • Polygons 0
  • Vertices 0
  • Textures
  • Materials
  • UV Mapping
  • Unwrapped UVs
  • Plugins used
  • Ready for 3D Printing
