DESCRIPTION

High-quality 3D model of a 500kg capacity reversible roller conveyor, engineered for industrial applications. This detailed design features a SEW motor driving φ76 rollers and a double SMC cylinder lift system integrated with a chain conveyor. Designed in SolidWorks 2018, the model includes precise structural components as used in real-world production lines. Ideal for simulation, layout planning, and manufacturing reference.

Specifications:

Load Capacity: 500kg

Roller Width: ~660mm

Motor: SEW Drive

Lift Mechanism: Double SMC Cylinder (φ160)

Roller Diameter: 76mm

Software: SolidWorks 2018

Formats: .step, .stp, .sldprt, .sldasm

Use Case: Industrial Equipment / Factory Automation
