DESCRIPTION

Steel Pedestrian Bridge

Sailing Column Type Construction

Two Column Consruction

Open Top Construction

Straigth Beam Type

Curved Column Type

Platfrom With Steel Rope Tensioning System

Named Objects

Largest Column Span : 48,74 mt.

Distance Between Two Columns : 48,74 mt.

Platform Asphalt Height : 6 mt.

Platform Width : 3 mt.

Elevator Steel Construction And Composite Coating

Elevator : width 2,25 mt * length 2,25 mt. * height 12,5 mt.

Elevator Cabin : not prepared

Escalator Composite Coating

Descending and Ascending Double Escalator

Escalator Steel Construction : not prepared

Escalator Step Size : width 300 mm. * length 800 mm. * height 165 mm.

Steel Rope : 16 piece

Rope Fixed Press : 16 piece

Rope Tensioning Press System : 16 Piece

Column Raft Concrete : width 2,5 mt * length 6 mt. * height 1 mt.

Escalator Raft Concrete : width 2,5 mt * length 4 mt. * height 1 mt.

Tension Column Raft Concrete : width 2,5 mt * length 2,5 mt. * height 1 mt.

Elevator Raft Concrete : width 2,5 mt * length 2,5 mt. * height 1,5 mt.

Steel Stair : not prepared

Flat Railing Construction

Railings Box Profile

Platform And Columns With Bolted Connection

Walking Surface : 2 cm. Rubber Flooring

Prepared With BLENDER Version 2.93.5

Polygons : 189920

Vertices : 293682

Objects : 4644
